Product Introduction

This locomotive uses AC driving technology,it has the advantages such as good sticking, big traction,wide range of speed regulation, high reliability,less cost for maintanance and etc. It is suitable for tracting of train in the main lane of mine, and on the ground.
The electric locomotive can be mainly used as a tractive device for trans-mission of mineral, equipment, equipment and personnel in opencast. Besides, it can also be used for rail bound transmission on the ground within factories or mines, where the power transmission lines (direct current of 250/550V) will supply the electric locomotive with power.

Main Parameter

Adhesion : 20t
Gauge:600mm/ 762mm/ 900mm
Hourly haulage : 18.9t/39.23t
Hourly speed : 15km/h
Max.haulage : 24.53kW/ 49kW
D.C Voltage : 550V
Traction motor * set : 78kW*2 or 85kW*2
L*W*H : 6600mm*1750mm/1600mm*1900mm/1320mm
Height of hauling: 595mm/780mm
Wheel base : 2200mm
Speed regulating mode : resistor speed regulating /IGBT
Min.turnning radious :30m
Braking mode : mechanical / electrical /air
Usage : underground mining transportation ,tunneling ,construction
We produce customer-made electrical locomotive with various specifications as customer's requests .

Figure Photos
